PMC MB2S XBD

PMC

The MB2S XBD builds on the acclaimed MB2S, delivering enhanced dynamics and low-frequency (LF) performance. The addition of the XBD cabinet, which houses a second precision 12” Radial™ driver, boosts LF headroom by 3dB below 380Hz, allowing larger rooms to be energised with greater impact. In surround setups, the extra headroom of the XBD easily manages the .1 effects channel, often eliminating the need for additional sub units. Found in quality-focused facilities like Studio Hilversum in the Netherlands, the MB2 XBD’s 32-element, 4th-order passive crossovers are housed in external enclosures that can be mounted on the back of the XBD cabinets, ensuring exceptional fidelity.

An outstanding choice for music recording, mastering, and post-production in both stereo and surround configurations.

Frequency response: 20Hz - 25kHz

Sensitivity: 91dB 1W 1m

Recommended Amp Power: 250-900W

Effective ATL™ Length: 2 x 3m 10ft

Impedance: 4 Ohm nominal

Drive Units: LF x 2 310mm PMC Radial™ driver; MF 75mm PMC fabric dome; HF 27mm PMC fabric soft dome

Crossover frequency: 380Hz & 3.8kHz

Input Connectors: 3 Pairs 4mm Sockets (Tri-wire or Tri-Amp)

Product Type: Passive studio monitor

lwh: 1740x380x535 mm

Weight: 88000 g
